Product Details
Place of Origin: China
Brand Name: DaLi
Certification: CE
Model Number: PE/PP tranparent/clear film/sheet production line
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 100000--180000 USD Per Set
Packaging Details: Regular Packing with blanket and stretch film or customized requirment package !
Delivery Time: 2-3 months
Payment Terms: T/T
Supply Ability: 5 sets per month
Name: |
PE /PP Clear/transparant Film/sheet Production Line |
Plastic Processed: |
PP/PE Grannule |
Application: |
Sheet/ Film |
Material: |
Granule |
Voltage: |
380V 3P/50HZ, It Can Be Customized |
Power(w): |
180KW |
Screw Design: |
Single Screw Extruder |
Certification: |
CE |
Usage: |
PE Film/CPE/TPE Film For Disposable Hand Glove |
Thickness: |
0.001mm--0.05mm |
Weight: |
12T |
Dimension(l*w*h): |
12mx4mx3m |
Output: |
1.5T--3.5T/24 Hours |
Name: |
PE /PP Clear/transparant Film/sheet Production Line |
Plastic Processed: |
PP/PE Grannule |
Application: |
Sheet/ Film |
Material: |
Granule |
Voltage: |
380V 3P/50HZ, It Can Be Customized |
Power(w): |
180KW |
Screw Design: |
Single Screw Extruder |
Certification: |
CE |
Usage: |
PE Film/CPE/TPE Film For Disposable Hand Glove |
Thickness: |
0.001mm--0.05mm |
Weight: |
12T |
Dimension(l*w*h): |
12mx4mx3m |
Output: |
1.5T--3.5T/24 Hours |
Use LDPE,LLDPE,PP as raw material.Screw use special mixing function and high plasticizing capacity design,guarantee better plasticizing.Hydraulic screen changer and high-efficiency cooling roller are used to ensure film shaping effect during production.Film edge can be recycled on-line,reduce the production cost.Double-station rotating-disc type winding system has both central and contact winding function,auto cutting,auto changing roll,online slitting function,no need secondary slitting,can save time and labor.Automatic adjustable die and auto thickness controller are optional.
Material |
PE/PP material |
Working width |
1000---2500mm max |
Thickness range |
0.012mm to 0.05mm |
Screw Dia. and L/D |
Φ110--Φ150×30:1---35:1 |
T die width | 1300--2800mm |
Substrcture of Layers | single or multiple |
Actual comsumption of power(KW) | 70--90KW per hour |
Power supply | Three Phase 380V( ±10% )50hz, Single Phase 220V50Hz |
Mechanical speed: | 10--90 m/min |
Extrusion capacity | 150~350kg/h(varies with material) |
Installation power(KW) |
About 180kw ( actual consumption is 40%-50% of total installation power) |
Installation space |
L=12.5M; W=5.5m; H=3.5m
|
Scene of assmebly workshop
